Twenty-eight module models across six sub-families — with the PON line (16 Huawei HiSilicon-based OLT modules) as the family's centre of gravity, and SFP/SFP+, video SFP and 1x9 modules around it.
Most converter manufacturers treat SFP modules as an accessory. This catalogue's module shelf has a distinct centre of gravity: sixteen PON modules built on Huawei HiSilicon chipsets — GPON OLT, XG-PON and XGS-PON classes at documented reaches — flanked by the general-purpose module families: SFP and SFP+ transceivers, video SFP transceivers for the broadcast plant this company also serves, and 1x9 optical transceivers for legacy sockets. This page is the family's map, deliberately led by its two unbound pillars: the XGS-PON line and the GPON OLT line, each with its own page below.
Why lead with PON? Because access-network optics are the highest-value modules in the catalogue (the XGS-PON class carries the strongest commercial demand of any module line here) and because they are the modules buyers most often fail to specify completely — class, reach and chipset generation all matter, and all three are printed in this family's model names. The general SFP/SFP+ modules serve the converter and switch plant across this site; the video SFPs serve the SDI families; the 1x9s serve installed sockets that predate SFP itself.
| Model (official product name) | Series | Documentation |
|---|---|---|
| Huawei HiSilicon E-link SFP 2488M (Tx) 1244M (Rx) GPON OLT Class D 20km (LNK-OM5070AX300) | — | Full specification confirmed per model at quotation |
| Huawei HiSilicon E-link SFP 2488M(Tx)1244M(Rx) GPON OLT Class C+ 20 km (LNK-OM5070AX200) | LNK-OM5070AX200 | Specification captured from the official product page |
| Huawei HiSilicon E-link SFP+ 9953M(Tx)2488M(Rx)&2488M(Tx)1244M(Rx) XG- PON&GPON OLT Class D 20km | — | Full specification confirmed per model at quotation |
| Huawei HiSilicon E-link SFP+ 9953M(Tx)2488M(Rx)&2488M(Tx)1244M(Rx) XGPON&GPON OLT Class C+ 20km | — | Full specification confirmed per model at quotation |
| Huawei HiSilicon E-link SFP+ 9953M(Tx)9953M&2488M(Rx) XGS-PON OLT E1 20km (LNK-OM5270SX600) | — | Full specification confirmed per model at quotation |
| Huawei HiSilicon E-link SFP+ 9953M(Tx)9953M&2488M(Rx) XGS-PON OLT E2 20km (LNK-OM5270SX700) | — | Full specification confirmed per model at quotation |
| Huawei HiSilicon E-link SFP+ 9953M(Tx)9953M&2488M(Rx) XGS-PON OLT N1 20km (LNK-OM5270SX400) | — | Full specification confirmed per model at quotation |
| Huawei HiSilicon E-link SFP+ 9953M(Tx)9953M&2488M(Rx) XGS-PON OLT N2 20km (LNK-OM5270SX500) | — | Full specification confirmed per model at quotation |
| Huawei HiSilicon E-link SFP+ 9953M(Tx)9953M&2488M(Rx)&2488M(Tx)1244M(Rx) XGS- PON&GPON OLT 20km | — | Full specification confirmed per model at quotation |
| Huawei HiSilicon E-link SFP+ 9953M(Tx)9953M&2488M(Rx)&2488M(Tx)1244M(Rx) XGSPON&GPON OLT 20km | — | Full specification confirmed per model at quotation |
| Huawei HiSilicon E-link SFP28 25G 20km (LNK-OM6363TX102) | — | Full specification confirmed per model at quotation |
| Huawei HiSilicon E-link SFP28 25G LR 10km (LNK-OM6363LX102) | — | Full specification confirmed per model at quotation |
| Huawei HiSilicon E-link SFP28 25G LR BiDi 10km(LNK-OM6363LX103 & LNK-OM6363LX104) | — | Full specification confirmed per model at quotation |
| Huawei HiSilicon E-link TSFP+ 10G DWDM 40km (LNK-OM6253EX200) | — | Full specification confirmed per model at quotation |
| Huawei HiSilicon E-link TSFP+ 10G DWDM 80km (LNK-OM6253ZX210) | — | Full specification confirmed per model at quotation |
| Huawei HiSilicon E-link TSFP+ 10G DWDM 80km(LNK-OM6253ZX200 & LNK-OM6253ZX201) | — | Full specification confirmed per model at quotation |
| 1.25Gb/s 120km CWDM SFP Transceiver | LNK-CSFP-1G | Specification captured from the official product page |
| 1.25Gb/s 80km CWDM SFP Transceiver | — | Full specification confirmed per model at quotation |
| SFP AOC DAC Handheld Optical Detector | — | Full specification confirmed per model at quotation |
| 10Gb/s 120km SFP+ Transceiver | LNK-10GZR-120 | Specification captured from the official product page |
| 10Gbps 1.4km 1310nm SFP+ Optical Transceiver | — | Full specification confirmed per model at quotation |
| SFP-GE-100FX 1000base-x to 100base-Fx SFP Transceiver | — | Full specification confirmed per model at quotation |
| 10Gb/s 10km CWDM SFP+ Transceiver | LNK-CSFP-10G | Specification captured from the official product page |
| 10Gb/s 40km CWDM SFP+ Transceiver | LNK-CSFP-10G | Specification captured from the official product page |
| 10Gb/s 80km CWDM SFP+ Transceiver | — | Full specification confirmed per model at quotation |
| 3G-SDI CWDM 1270~1610nm 40km Digital Video SFP Optical Transceiver (MSA) | — | Full specification confirmed per model at quotation |
| 155M Single Fiber BIDI 1x9 Optical Transceiver | — | Specification captured from the official product page |
| 155M Single Mode 1x9 Optical Transceiver | — | Full specification confirmed per model at quotation |
PON modules (16) + SFP Transceiver (3) + SFP+ Transceiver (3) + Video SFP Transceiver (4) + 1x9 Optical Transceiver (2) = 28 models, as listed in the manufacturer's catalogue. QSFP-family modules have their own page.
Host first (OLT, converter, switch, camera), then the standard (GPON/XGS-PON/Ethernet/video), then class and reach. A module inquiry that starts from the host device gets a compatible answer the first time.
GPON Class C+ and Class D, XGS-PON E1/E2 and N1/N2 differ in optical budget — the split ratio and reach the ODN can support. State the ODN design (split, distance) and the class is matched to it, not merely to the port.
Video SFP transceivers pair with the SDI converter plant (including the micro-extender pattern). If the module is for a video host, name the host and the rate (HD/3G/12G).
The family is documented as Huawei HiSilicon-based modules — the chipset lineage is in the family name itself. Host compatibility is confirmed per host model in the quotation; state your OLT platform plainly.
The QSFP family — 100G QSFP28, 40G QSFP+, 50G QSFP28 and 400G QSFP-DD — has its own page, one click from here in the Optical Modules menu.
A link's two ends must agree on standard, wavelength plan and budget class. Mixed-vendor links are normal in optics when the parameters agree — the parameters, confirmed in writing, are the requirement.
Send the model name, the distance, the fiber type and the quantity. We will confirm the matching transmitter/receiver pairing, the optical module and the full specification of the exact model in writing before you pay.
